## Introduction to Crane Sizes

There are many factors to consider when trying to calculate what size crane you need. In this free guide to crane sizes we focus on covering mobile crane sizes. We have included a simple table that you can use to quickly estimate the crane size you will need based on the weight of your item and the radius (which we will explain further). However, almost no lifting operation is identical and this is the reason that only qualified Appointed Persons should choose a suitable crane size and crane type for your job. This crane size guide acts as a starting point for anyone wanting to approximate the logistical viability of their project and assess the scale of their lifting requirements. If you don't want to wrap your head around this guide, just get in touch with us via our website live chat, send us and email or pick up the phone and we will offer friendly advice and give you a no obligation crane hire quotation today.

### How is this crane size guide broken down?

We first cover the three main factors that influence the crane size you need - weight, radius and height. We then take a look at the numerous other factors that can play a part in determining the crane size you need such as space and crane configuration. Following this, there is a simple crane size calculation chart which helps you to estimate the crane size you need based on the weight and radius of your lift. The following section explains in a bit more detail how to check that a crane is capable of completing your lifting operation by using the crane specification sheet. Finally, this crane size guide summarises the information discussed and explains what you can do to get your definitive crane size and crane hire cost.

### Contents For This Guide

If you don't have time to read this guide and just want to get a crane hire price, use our live chat or contact us and we will give you an indication of prices straight away.

## Weight, radius and height - 3 crane size influences

When calculating what crane size you need, there are many variables to consider. The three most important are weight, radius and height. A crane size estimate can be based on the weight and radius but the height of the lift is almost equally important when checking a crane size is suitable for a specific lifting operation. If there are no obstructions to the lift, such as buildings, or the item does not need to be lifted high then the height is less important than the weight and radius when determining crane size.

### What is the weight, radius and height?

The table gives an explanation of these factors and outlines what affect they can have on the crane size required.

 Factor Description Weight Quite simply, what is the weight of the item you need lifting? In addition to the item's weight, there is also the weight of the tackle and crane hook to consider but these can vary depending on the type of crane and the lift. Radius How far does the item need lifting? This is the distance from the centre of the crane's slew ring to the centre of gravity of the load's furthest position from the crane. Height How high does the crane need to lift? If the crane is positioned close to a building, then it will need to telescope out higher to achieve the radius required.

### How do I find the weight, radius and height to help determine what size crane I need?

Usually you can find out the weight of an item by looking at its specification sheet - if it does not have one then you will need to contact the manufacturer to confirm the weight. If the weight on the day is different to that used to plan the lift, then you will end up either paying for a crane larger than necessary or the lift will not be possible. The radius is simply measured (in metres) using a tape measure or distance meter - to do this, measure horizontally the distance from the centre of the cranes slew ring in the position it will set up to the centre of gravity of the loads furthest point from this. Finally, the height of the lift can be determined by either the dimensions of the object or obstructions to the lift such as buildings - this should also be measured in metres.

Important NoteIf you have a contract lift instead of a crane hire, the hire firm will be responsible for choosing a suitable crane size and crane type.

Read our full guide to the differences between crane hire and contract lifts if you want to understand more about this.

Our guide to the different types of cranes is coming soon.

## Other factors affecting crane size

Weight, radius and height are just three of many factors to consider when determining the final crane size needed. In reality there are many more things to consider when determining what size crane you need and for this reason you should have an Appointed Person properly plan the lift. The table below outlines just a few examples of other factors that can affect the crane size you need.

 Factor Description Tackle / Equipment The weight of the tackle under the hook can vary depending on the item being lifted and how it needs to be slung - for example, spreader beams may be required and this can significantly increase the weight under the hook and consequently the crane size needed. Hook Block Configuration The correct hook block configuration needs to be determined for the lift and this can be affected by a number of factors such as the item being lifted and the weight of the item. Different hook blocks can have different weights and this needs accounting for when considering overall lifting capacity. Obstructions Obstructions such as buildings, underground services and overhead cables can all influence where a crane is able to setup. Consequently, this can increase the crane's radius, main boom and ultimately the crane size. Railways When carrying lifting operations over or adjacent to a live railway line, and in all circumstances where a crane and its load can collapse within four metres of a railway asset or property boundary, Network Rail must be consulted at the earliest stage of planning. This can influence where a crane can set up and also the crane size required due to a potentially increased radius. Confined Spaces When there is limited space for a mobile crane, it might only be feasible for it to half rig. When half rigged, the lifting capacity decreases and therefore you may need a larger crane size than orginally anticipated to be able to complete lifting operations. Crane Configuration Sometimes, it may be more economical to have a smaller crane with a fly jib attached to increase the lift radius instead of hiring in a larger crane without a fly jib. Likewise, it is sometimes more economical to hire larger crane with less ballast than a smaller crane with full ballast. Decisions like this are difficult to make unless you are an experienced crane hire professional. Other Factors The list really does go on and there are numerous site specific factors that come into consideration when determining what size crane and what type of crane are suitable for your job. Synergy Lifting provide a full contract lift service - get in touch for your free advice today and to get your tailored quotation.

Important NoteWho is responsible for selecting the crane size and type?

• Crane hire service - customer's responsibility.
• Contract lift service - crane firm's responsibility.

## Estimate your crane size with our size chart

Use our mobile crane size chart to estimate the crane size you need for your project. Please note that this crane size calculator should only be used as a guide and no account is taken for the height of lift or any other factors affecting the crane size you need.

Using the crane size chart is simple, follow these steps:

1. Locate the weight of the load in the left column.
2. Locate the crane radius in the top row.
3. Where the column and row intersect, read the estimated size of mobile crane required for this lift.
 t\m 7m 8m 9m 10m 12m 14m 16m 18m 20m 22m 24m 26m 28m 30m 32m 34m 36m 38m 40m 42m 44m 46m 48m 50m 52m 54m 0.5t 20t 20t 20t 20t 20t 20t 20t 20t 20t 20t 25t 25t 35t 35t 50t 50t 70t 70t 80t 80t 80t 90t 120t 120t 120t 120t 1t 20t 20t 20t 20t 20t 20t 20t 20t 25t 25t 35t 35t 50t 50t 60t 70t 70t 70t 80t 80t 90t 100t 120t 120t 120t 120t 2t 20t 20t 20t 20t 20t 20t 25t 25t 35t 35t 50t 50t 60t 60t 70t 80t 80t 80t 90t 100t 100t 120t 120t 160t 160t 160t 3t 20t 20t 20t 20t 20t 25t 35t 35t 50t 50t 60t 70t 70t 80t 80t 90t 90t 100t 100t 120t 120t 160t 160t 160t 200t 200t 4t 20t 20t 20t 20t 25t 35t 35t 50t 50t 60t 70t 80t 80t 90t 90t 100t 100t 120t 120t 160t 160t 160t 160t 200t 225t 225t 5t 20t 20t 25t 25t 35t 35t 50t 50t 60t 70t 80t 80t 90t 100t 100t 120t 120t 160t 160t 160t 160t 200t 200t 225t 250t 300t 6t 25t 25t 25t 25t 35t 50t 50t 60t 70t 80t 90t 90t 100t 100t 120t 160t 160t 160t 160t 160t 200t 225t 225t 225t 250t 300t 7t 25t 25t 25t 35t 50t 50t 60t 70t 80t 90t 100t 100t 120t 120t 160t 160t 160t 160t 200t 200t 225t 225t 250t 250t 300t 300t 8t 25t 35t 35t 35t 50t 60t 60t 80t 90t 90t 100t 120t 120t 160t 160t 160t 200t 200t 225t 225t 250t 250t 250t 300t 300t 800t 9t 35t 35t 35t 50t 50t 60t 70t 80t 90t 100t 120t 120t 160t 160t 160t 200t 225t 225t 225t 250t 250t 250t 300t 300t 800t 800t 10t 35t 35t 35t 50t 60t 70t 80t 90t 100t 120t 160t 160t 160t 160t 200t 225t 225t 225t 250t 250t 250t 300t 800t 800t 800t 800t 11t 35t 35t 50t 50t 60t 80t 90t 100t 100t 120t 160t 160t 160t 200t 225t 225t 250t 250t 250t 300t 300t 300t 800t 800t 800t 800t 12t 35t 50t 50t 50t 70t 80t 100t 100t 120t 120t 160t 160t 160t 200t 225t 225t 250t 250t 300t 300t 300t 400t 800t 800t 800t 800t 13t 35t 50t 50t 60t 80t 80t 100t 120t 120t 160t 160t 160t 200t 200t 225t 250t 250t 250t 300t 300t 400t 400t 800t 800t 800t 800t 14t 50t 50t 50t 60t 80t 90t 100t 120t 120t 160t 160t 200t 200t 225t 250t 250t 250t 250t 300t 400t 400t 400t 800t 800t 800t 800t 15t 50t 50t 60t 70t 80t 100t 100t 120t 160t 160t 160t 200t 225t 225t 250t 250t 250t 300t 400t 400t 400t 400t 800t 800t 800t 800t 16t 50t 50t 60t 70t 80t 100t 120t 120t 160t 160t 200t 200t 225t 250t 250t 250t 300t 400t 400t 400t 400t 400t 800t 800t 800t 800t 17t 50t 60t 70t 70t 90t 100t 120t 160t 160t 160t 200t 225t 225t 250t 250t 300t 300t 400t 400t 400t 400t 400t 800t 800t 800t 800t 18t 60t 70t 70t 80t 90t 100t 120t 160t 160t 200t 200t 225t 250t 250t 250t 300t 400t 400t 400t 400t 400t 500t 800t 800t 800t 800t 19t 60t 70t 70t 80t 100t 120t 120t 160t 160t 200t 200t 225t 250t 250t 300t 400t 400t 400t 400t 400t 400t 500t 800t 800t 800t 800t 20t 60t 70t 80t 80t 100t 120t 160t 160t 200t 200t 225t 225t 250t 250t 300t 400t 400t 400t 400t 400t 400t 500t 800t 800t 800t 800t 21t 70t 70t 80t 80t 100t 120t 160t 160t 200t 200t 225t 250t 250t 300t 400t 400t 400t 400t 400t 400t 400t 500t 800t 800t 800t 800t 22t 70t 70t 80t 90t 100t 120t 160t 160t 200t 225t 225t 250t 250t 300t 400t 400t 400t 400t 400t 400t 500t 800t 800t 800t 800t 800t 23t 80t 80t 80t 90t 100t 120t 160t 160t 200t 225t 225t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 800t 800t 800t 800t 800t 24t 80t 80t 80t 90t 120t 160t 160t 200t 200t 225t 250t 250t 300t 400t 400t 400t 400t 400t 400t 500t 500t 800t 800t 800t 800t 800t 25t 80t 80t 90t 100t 120t 160t 160t 200t 225t 225t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 800t 800t 800t 800t 800t 26t 80t 80t 90t 100t 120t 160t 160t 200t 225t 250t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 800t 800t 800t 800t 800t 27t 80t 80t 90t 100t 120t 160t 160t 200t 225t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 800t 800t 800t 800t 800t 800t 28t 80t 80t 90t 100t 120t 160t 200t 200t 225t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 800t 800t 800t 800t 800t 800t 29t 80t 90t 100t 100t 160t 160t 200t 225t 250t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 800t 800t 800t 800t 800t 800t 30t 80t 90t 100t 100t 160t 160t 200t 225t 250t 300t 300t 300t 400t 400t 400t 400t 400t 500t 500t 800t 800t 800t 800t 800t 800t 800t 31t 80t 90t 100t 120t 160t 160t 225t 225t 250t 300t 400t 400t 400t 400t 400t 400t 400t 500t 500t 800t 800t 800t 800t 800t 800t 800t 32t 80t 90t 100t 120t 160t 160t 225t 225t 250t 300t 400t 400t 400t 400t 400t 400t 400t 500t 500t 800t 800t 800t 800t 800t 800t 800t 33t 90t 100t 100t 120t 160t 160t 225t 225t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 500t 800t 800t 800t 800t 800t 800t 800t 34t 90t 100t 100t 120t 160t 200t 225t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 800t 800t 800t 800t 800t 800t 800t 800t 35t 90t 100t 100t 120t 160t 200t 225t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 800t 800t 800t 800t 800t 800t 800t 800t 36t 100t 100t 120t 160t 160t 200t 225t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 800t 800t 800t 800t 800t 800t 800t 800t 800t 37t 100t 100t 120t 160t 160t 200t 225t 300t 300t 400t 400t 400t 400t 400t 400t 500t 500t 800t 800t 800t 800t 800t 800t 800t 800t 800t 38t 100t 100t 120t 160t 160t 200t 225t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 800t 800t 800t 800t 800t 800t 800t 800t 800t 39t 100t 100t 120t 160t 160t 225t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 800t 800t 800t 800t 800t 800t 800t 800t 800t 40t 100t 100t 120t 160t 160t 225t 250t 300t 300t 400t 400t 400t 400t 400t 500t 500t 500t 800t 800t 800t 800t 800t 800t 800t 800t 800t Please note: (1) this is a load radius chart and no account has been taken for the height of lift, (2) this chart is based on using a minimum main boom length of 20.0m (3) crane capacities will vary from manufacturer to manufacturer (4) lifting capacities will vary with crane type (Truck Mounted or All Terrain).

AdviceIf you want to know the exact crane size you will need then get in touch with us and we will let you know what we need to determine this. Feel free to ask us questions using our website's live chat feature or get in touch with us via email or phone.

## Checking crane size with a crane spec sheet

Before you try to wrap your head around this information, you should understand that we can work out the suitable crane size for you - this information is for anyone who wants to learn more about the process and to give a brief insight into the methods involved. When you have used the crane size estimator in the section above, find the technical specification sheet for a crane of that size and you will be able to see if it is capable of doing the lift. As an example, we have illustrated this for you to show you how you can check that a crane size is suitable by drawing a few lines on a crane specification sheet.

### Step 1 - check the crane size dimensions and outrigger base

You must first locate the page illustrating the cranes dimensions. This will allow you to see if the crane will fit in the desired position on site based on the crane size dimensions. Note that the crane will need to drive into position and then extend its outriggers. Click the image below and you can see that the outrigger base for a Demag AC 50-1 mobile crane is 6.85m by 6.4m and the overall length of the crane is 11.2m.

### Step 2 - position the crane

If the crane fits in the desired location on site, you must then make sure that you plot any potential obstructions to the lifting operations on the graph. In our example, let us assume that the crane is set up 8m from the edge of a tall building. We begin by measuring and plotting 8m along the horizontal axis - this is equal to distance from the centre of the slew ring to the edge of the building that is a potential obstruction to the lift. In the image, this is illustrated by a red line.

### Step 3 - height of obstructions

Now that we have plotted the distance from the crane to the building, we need to plot the total height of the building. We need to do this to ensure that the crane's main boom will be able to reach over the building to achieve the desired radius. Make sure you have an accurate height for the building because this can affect the crane size and ultimately the cost for your crane hire. In our example, the building is 12m high and this is illustrated by the pink line in the image which has been plotted on the graph.

### Step 4 - plot the radius

Now that you have the crane set up in the correct location relative to any obstructions, you need to plot the radius that you need the crane to reach for your lift. This is measured in metres from the centre of the crane's slew ring to the furthest location of the load being lifted. In our example, the desired radius is 16m and this is illustrated by the green line drawn vertically from the 16m mark on the horizontal axis.

### Step 5 - plot the main boom

Now that we have the desired radius plotted, we need to make sure the crane can achieve this whilst avoiding any obstructions we have plotted. To do this, you must draw a straight line that from the centre of the crane's slew ring until it intersects with the line drawn for the radius measurement (i.e. the green line) whilst avoiding any obstructions (i.e. the pink line). Also bear in mind that there should be a comfortable amount of room for any margin for error in the measurements taken for the obstructions height. In our example, this step is illustrated by the blue line.

### Step 6 - check the main boom length

The final step to complete using the graph plot is to determine the minimum main boom length required for this lifting operation. In our example, this is illustrated by the orange line drawn on the image - following this back we can see that the required minimum main boom length in our example is 37m.

### Step 7 - check the lifting capacity

Now you have the checked that the radius can be achieved and you know the required boom length, you must turn to the corresponding lifting capacities data table - usually the previous or the following page in the crane specification. There are often numerous lifting capacity data tables based on the cranes setup - e.g. the total counterweight / ballast and whether it is fully rigged or half rigged. Start with the first lifting capacity data table and identify the radius and main boom length - in our example this is a 16m radius and a 37m main boom length. Find where these intersect and that is the maximum lifting capacity - in our example the crane can lift 5.6te based on our working ranges (sometimes it can be beneficial to increase the main boom length because it can increase the lifting capacity in some cases). Note that this lifting capacity data table is for the crane setup with 9.5te of ballast and fully rigged. It is worthwhile checking the other lifting capacity data tables to see if the lift can be completed with less ballast because this can often mean you can either use a smaller crane size or the crane can travel with less ballast which can be cheaper.

Search for and download crane specification sheets for a range of cranes.

ExampleIn this example, we have chosen to use a Demag AC 50-1 mobile crane. Please note that this is for illustration purposes only and you must contact us to confirm the detailed technical specification for the this crane. This example is intended to give you a better insight into how an Appointed Person calculates a suitable crane size for a project. There are many more factors to consider and crane configurations which can increase or decrease the actual crane size required - this example is only meant as a starting point.

## What size crane do I need?

To summarise, calculating the crane size you need can be a bigger task than first expected. There are many factors that need to be accounted for. The main factors are weight, radius and height but it is also important to go beyond this and consider other factors such as obstructions, space and the crane's configuration. Using our crane size chart above is a good starting point if you are trying to get a rough idea of the approximate scale of your lifting operation but it is important to have an Appointed Person determine the actual crane size and crane type that is required for your project.

### How do I know for certain what size crane I need?

Finding out that there is no easy way to work out the crane size you need might seem frustrating at first but luckily for you this need not be a problem for you to solve. At Synergy Lifting, we offer free advice and supply crane hire and contract lift services across the UK. Use the live chat on our website and we will help to calculate the size crane you need and give you an indication of pricing. If suitable, we can conduct a free site visit to discuss your crane requirements with you and come to a firm crane hire cost - feel free to get in touch today.

Read our full guide to learn how much crane hire costs.

Important NoteWho is responsible for selecting the crane size and type?

• Crane hire service - customer's responsibility.
• Contract lift service - crane firm's responsibility.
